Single Point Load Cells
Analogue Single Point Load Cells for Scales with Platform Sizes up to 800mm x 800mm
Which single point load cell is the right one for your application? Simply enter all important key data in the product finder and it will show you all suitable analogue load cells.
Click here for the product finder
HBM's Single Point Load Cell Options:
Load Cell for Aseptic Production:
PW27A: For Hygienic Weighing up to 20 kg
With load cells of the PW27A product series, companies producing and filling food products are well prepared to face all future challenges: Designed for low capacities ranging from 0 to 10kg and 0 to 20kg, the load cells comply with the strict EHEDG specifications and are therefore ideally suited for filling, packing, and weighing beverages and other food products.
Due to the special design of the stainless-steel measuring body in conjunction with the solid stainless-steel pipe housing, the PW27A load cells are hermetically sealed and extremely robust (IP68/IP69K degree of protection). This allows quick and thorough cleaning, even with high-pressure washers. Owing to their integrated and encapsulated overload protection—up to ten times their maximum capacity—the PW27A load cells’ functionality remains unchanged even if someone accidentally steps on them (e.g. when cleaning the machine).
A PW27AP version of the load cell—providing a connector for even faster integration—is also available.
The Universal Load Cell Series
Load cells SP4M and PW15 ...: weigh up to 200 kg and up to the highest possible degree of protection IP68 / 69K
The PW15 and SP4M series load cells have uniform footprint but different characteristics. They enable scales to be designed in a flexible design, thus enabling a wide range of applications. With their different specifications, they are ideal for the food, packaging and chemical industries as well as for trade and agriculture - and ideal for belt, floor, table and loading scales as well as filling and production systems.
- The SP4M certified single point load cell made of aluminum and a very large nominal load range weighs particularly precisely up to Accuracy Class C6 Multitrange and an enormous maximum factor (Y value) of up to 20,000. In addition to explosion-proof versions for potentially explosive atmospheres, the load cell is available with additional options such as different connection cable lengths and balanced output for parallel connection.
- The PW15B single point load cell is made of stainless steel and can therefore be used in a wide range of ambient conditions. It is also available in various explosion-proof versions, as well as with balanced output for optimum use in parallel-connected scales.
- The PW15AH single point load cell is enormously robust, hermetically encapsulated, has the highest possible degree of protection IP68 / IP69K. The PW15AH load cell provides stable results under extreme ambient conditions.
- The PW15PH single point load cell is extremely flexible and quickly replaceable thanks to an innovative plug system. With a hermetically welded device plug, it also fulfills protection class IP68 / 69K. The matching connection cables are also available from HBM.
The Compact Load Cell for Heavy Loads
PW10A Single-Point Load Cell: Weighing Heavy Loads with Class C3MR Precision
The PW10A load cell is ideally suited to be used in single-point applications that involve platform sizes up to 600 x 500 mm, such as in industrial applications and weighers or medical scales. Its maximum capacity is up to 300 kg, which is very high considering its compact design. The single-point load cell complies with the C3 Multi-Range accuracy class and provides precise measurement results. A test certificate confirms that it is approved for use in legal for trade applications. The 6-wire technology compensates for all cable influences on the measurement result. The PW10A load cell's cable shield is connected to the measuring body and thus optimally protects it against electromagnetic fields. The load cell withstands overloads of up to three times its maximum capacity, owing to its highly resistant aluminum measuring body. The single-point load cell complies with the IP67 degree of protection and is optimally suitable for use in industrial environments. The PW10A has an excellent price-to-performance ratio. An explosion-proof version in compliance with IECEx+ATEX is also available.
- Accuracy class: C3 Multi-Range
- Maximum capacity: 50 kg to 300 kg
- Dimensions: 44 x 174 x 38 mm (W x H x D)
The Single-Point Load cell for Large Platforms
PW12C Single-Point Load Cell: Weighing Precisely with Large Platforms
The PW12C single-point load cell complies with the C3 Multi-Range accuracy class and provides precise weighing results. It is suited to be used in both static and highly dynamic applications, for instance, in checkweighers, for the weighing of building materials or the filling of fluid and gas. It provides optimal weighing results, owing to its integrated off-center load compensation, and is ideal for single-point applications involving large weighing platforms of up to 800 x 800 mm.
The PW12C comes with high stiffness and proven HBM strain-gauge technology, thereby demonstrating dynamics that are unique in the market. The single-point load cell has an individually adjustable overload protection mechanism. The PW12C is resistant to humidity and dirt due to its IP67 degree of protection. Its cable shield is connected to the measuring body and thus optimally protects the load cell against electromagnetic fields. An explosion-proof version of the PW12C is also available as well as a version with a balanced signal output for connection in parallel.
- Accuracy class: C3 Multi-Range
- Maximum capacity: 50 kg to 750 kg
- Maximum platform size: 800 x 800 mm
The Single-Point Load Cell for a Wide Range of Applications
Pw16A — The Single-Point Load Cell for Applications With High Cycle Rates
The PW16A single-point load cell has a short settling time and is, thus, suitable for many industrial applications that involve high cycle rates. For instance, in checkweighers, filling of fluid and gas, or the weighing of building materials. The PW16A offers high stiffness and uses proven HBM strain-gauge technology, thereby providing precise results in compliance with the C3 Multi-Range and C4 accuracy class even when weighing at very high speeds.
The PW16A is the ideal solution that meets individual requirements, owing to its ten different maximum capacities, ranging between 30 and 660 kg, and many available options and cable lengths. It is ideal for single-point applications involving large weighing platforms up to 600 x 600 mm, owing to its integrated off-center load compensation. A version with a balanced signal output for connection in parallel is also an available option. The single-point load cell is based on the 6-wire technology and its cable shield is connected to the measuring body, thereby allowing it to provide dependable measured data, even in environments affected by electromagnetic fields. A test certificate confirms that the PW16A is approved for use in legal-for-trade applications. An explosion-proof version in compliance with IECEx+ATEX is also available.
- Accuracy class: C3 Multi-Range and C4
- Maximum capacity: 30 kg to 660 kg
- Degree of protection: IP67
Optimized Sulotion for Dynamic Weighing Tasks
PW28 Single Point Load Cells for Precise Weighing of Masses from 5 kg to 75 kg
Owing to its ratio of minimum verification interval of up to 20,000, the PW28 single point load cell complies with the C3 multi-range, or, optionally, the even higher C4 MR accuracy class, providing extremely precise results. It is suitable for both static and dynamic applications due to its high stiffness. Stainless-steel housing and IP67 degree of protection permit reliable operation in industrial environments. All PW28 load cells, irrespective of their maximum capacity, feature integrated and encapsulated overload protection, ensuring stability against unexpected overload.
- Accuracy class: C3 MR, C4 MR in compliance with OIML R60
- Nominal (rated) measuring range: 5 kg to 75 kg
The High-Speed Load Cell for Dynamic Weighing
PW22 Single Point Load Cell: Extremely Fast Weighing with Accuracy Class C3
The PW22 single point load cell is ideally suited for fast, dynamic weighing, for example in multihead combination weighers. With IP67 degree of protection, it is ideal for reliable use in industrial environments, for example filling bulk materials or in many other kinds of filling applications.
The PW22 has uniquely high rigidity and therefore an extremely high natural resonant frequency. This ensures low settling times, which in turn results in extremely short weighing times. With a high maximum scale interval factor and accuracy class C3, it returns reliable and has very precise measurement results. Thanks to the patented overload stop in compressive and tensile direction, it can withstand overloads of up to five times the maximum capacity. Available with protective housing, six maximum capacities between 6 kg and 90 kg, and different cable lengths, the PW22 single point load cell comes in an extensive range of versions. It has standard footprint for compatible usage. For even more demanding operating conditions, the PW22 is also available in an explosion-proof ATEX version.
- Accuracy class: C3 multirange
- Maximum capacity: 6 kg to 90 kg
- Degree of protection: IP67
Highly Precise Static Weighing
The PW2C Single Point Load Cell Weighs with Extremely High Precision up to the C6 Accuracy Class
The PW2C single point load cell weighs a maximum static load of 72 kg with extremely high precision up to the C3 MR (Multi-Range) or, optionally, the even higher C6 accuracy class. It is ideal for use in static industrial, medical, and commercial applications such as shop-counter, conveyor, or platform scales. The PW2C offers high precision, even with uneven load distribution, due to its high torsional stiffness and off-center load compensation. For instance, it is suitable for use with checkout scanners where the load cell cannot be positioned at the center.
- Accuracy classes: C3 MR (Multi-Range), C6
- Capacity: 7.2 kg to 72 kg
- Degree of protection: IP67
The Highly Dynamic Load Cell for Fast Weighing Process
The PW2D Single Point Load Cell Weighs a Maximum Load of 72 kg with High Speed
The PW2D single point load cell weighs a maximum load of 72 kg precisely up to the C3 MR (Multi-Range) accuracy class. The strain-gauge load cell is unique due to its extremely high natural frequency and ideal for use in highly dynamic weighing tasks involving short cycle times, for instance, in industrial weighing systems.
HBM’s PW2C load cell offers even higher accuracy with static measurements.
- Accuracy class: C3 MR (Multi-Range)
- Capacity: 7.2 kg to 72 kg
- Degree of protection: IP67
The Precise Load Cell for Static Multi-Range Measurement
PW6C Single Point Load Cell: Weighing of Static Loads of up to 40 kg
The PW6C single point load cell weighs static loads with high precision and is available with various capacities of up to 40 kg. It is ideally suitable for utlization in shop-counter scales as well as in conveyor and platform scales with only one load cell. The PW6C single point load cell is an excellent choice for multi-range applications due to its low temperature coefficient. The load cell’s increased nominal (rated) displacement enables overload stops to be easily implemented and precisely adjusted. Thanks to proven HBM technology, the PW6C single point load cell is available for multi-range applications, preset with accuracy class C3 MR (Multi Range).
- Accuracy class: C3 MR (Multi Range)
- Capacities: 3–40 kg
- Degree of protection: IP67
The Load Cell for Extremely Fast Weighing Processes
PW6D Single Point Load Cell: Highly Dynamic Weighing up to 40 kg
The PW6D single point load cell weighs static and, in particular, dynamic loads up to 40 kg with extremely high precision and speed. It displays an outstanding stiffness owing to its special design. The extraordinarily small nominal (rated) displacement ensures a high fundamental frequency that is unparalleled in the market. The PW6D single point load cell is therefore ideal for utilization in rapid weighing processes in industrial applications. The load cell has been optimized for dynamic applications to facilitate weighing at high speed. Manufacturers dealing in individual weighing system solutions can also benefit from the extensive range of PW6D variants.
- Accuracy class: C3 MR (Multi Range)
- Capacities: 3–40 kg
- Degree of protection: IP67
PW29: Hermetically Encapsulated Load Cell
The hermetically encapsulated PW29 is a single-point load cell for high maximum capacities and large weighing platforms. The load cell is made of stainless steel and is ideally suited for precisely weighing huge loads; for example, in the food and beverage industry, as well as in the pharmaceutical industry.
PW29 delivers reliable measurement results in compliance with OIML R60 regulations even in tough operating conditions. This is due to the sophisticated measuring body design and the specifically optimized strain gauge system and rugged design.
Moreover, PW29 meets the highest possible IP68/IP69K degree of protection. Use in dust environments is not a problem as well as applications involving exposure to water and humidity. Even cleaning with high-pressure cleaners or aggressive cleaning agents does not affect the load cell's proper functioning.
The Compact Load Cell for Large Platform Scales
PWSE Single Point Load Cell: Up to 750 kg Capacity and C3 Accuracy Class
The PWSE single point load cell weighs heavy loads ranging from 100 to 750 kg with C3 accuracy class. It is ideally suited for use in large platforms and conveyor scales. Owing to its very compact design, integration of the PWSE into various weighing systems is easy and takes up little space. The single point load cell is particularly robust, due to its stainless steel measuring body, the robust silicone rubber enclosure, and its IP67 degree of protection. Thus, the PWSE is ideal for use in harsh conditions such as the weighing of building materials or in the chemical industry.
Due to its special measuring body geometry and solid mounting with standard threaded bores, it ensures high measurement accuracy with platform sizes of up to 800 x 800 mm. Its excellent price/performance ratio makes the PWSE attractive for a wide range of applications. Proven for decades, it is being developed continually.
- Accuracy class: C3MR (Multi Range)
- Maximum capacities: 100 kg to 750 kg
- Degree of protection: IP67
The Heart of Weigh Fillers
FIT5A Digital Load Cell: The Heart of Weigh Fillers
Premium foods, too, are under increasing price pressure. For the manufacturers of filling machines this means that they need to ensure ever more precise filling to minimize overfill and increase output.
This requirement is met by using weigh fillers based on the FIT5A digital load cell. FIT5A is the result of over 10 years of close cooperation with the market leaders in this industry. Even the smallest detail of this load cell has been optimized for use in this type of machinery.
Specialized to perform batching tasks as well: Integrated filters and a filling algorithm make FIT5A the perfect candidate for batching tasks. It forms the heart of heavy-duty multi-head combination weighers or hopper scales.
- Confirmed precision: OIML certificate for C4, Y up to 25,000
- Maximum capacity: 5 kg ... 50 kg
Digital Single Point Load Cells
HBM's solutions for checkweighers, batching and filling systems
Whether your application is checkweighers or batching and filling systems – it's your choice! HBM provide you with the matching digital load cell and, in addition, with the right weighing electronics and software – all components from a single source, tailored to your application. Scroll down to get an overview!
HBM's Digital Single Point Load Cells Options:
Easy Care Load Cell for High Hygienic Standards
PW25 Load Cell: Hygienic Weighing Up To 20 kg
The PW25 provides extremely precise weights for food weighing up to 20 kg (accuracy class C3). With space-saving construction and market-compliant dimensions, the PW25 is easy to use in weigh fillers, multi-head combination weighers and for traditional weighing tasks. The PW25 load cell with IP rating IP69K features extraordinary tightness. Integrated overload protection ensures an overload stability of 1000% the maximum capacity.
In addition it is easy to clean, which makes it especially suitable for hygienically critical applications in the food industry such as filling containers of milk, baby food and yogurt. The load cell is also optionally available as the PW25P with a connector plug for even faster integration.
- Accuracy class: C3 multirange
- Maximum capacities: 10 kg, 20 kg
- Degree of protection: IP68/IP69K
The Heart of The Checkweigher
FIT7A Digital Load Cell: The Heart of Checkweighers
The future of checkweighing starts with the FIT7A digital load cell. With FIT7A, for the first time you can build your own checkweigher for your packaging line. There is no need for you to purchase expensive components and you become more competitive and independent.
Why opt for the checkweigher load cell from HBM? We are a pure supplier of weighing technology components. Therefore you do not purchase your components from your potential competitors. We are a dependable global partner offering high delivery reliability. Always near you: With a strong sales and service team that looks forward to providing personal support, answering your questions and offering professional training.
- Confirmed precision: OIML certificate for C6, Y up to 50,000
- Maximum capacity: 3 kg ... 75 kg
Beam Load Cells
In almost all sectors where goods are produced, processed or controlled, a HBK Beam Load Cell and weighing technology component can be found. For the majority of HBK Beam Load Cells official approval certificates are available. Many load cells are also available for the various zone areas in accordance with the valid ATEX directive.
Z6 Bending Beam Load Cell
The Market Standard for Precision and Robustness in the Weighing Range from 5 kg to 1 t
The precise Z6 bending beam load cell, developed by HBM in 1972, has been continuously optimized for decades. Z6 is based on the strain gauge technology. It is available in nine different versions with maximum capacities that range from 5 kg to 1 t. The load cell with the characteristic bellows has become a worldwide standard, with millions of load cells having been sold. It is employed in platform and conveyor scales for dosing and level measurement as well as in weighing modules that, for instance, are used for tank weighing applications. The metal bellows protects the load cell against the ingress of moisture. The Z6 load cell has been optimized for connection in parallel. An IECEx-ATEX-compliant explosion-proof version is also available.
- Accuracy class (OIML): up to C6
- Nominal load: from 5 kg to 1 t
- Degree of protection: IP 68
Precise Weighing Modules for Maximum Stability
Z6M and Z6AM Weighing Modules for Precise Weighing up to 500 kg
The Z6M and Z6AM weighing modules come with HBM’s high-quality series Z6F load cells and allow very precise measurement. They are ideal for use in the food, building, and pharmaceutical industries. Sturdy design and capacity up to 500 kg ensure stability of tanks and silos. The Z6M and Z6AM have self-centering rocker pins that ensure optimal force application. They allow fast and easy integration owing to pre-assembled load cells. The module is immediately ready for use, maintenance-free, and can be used in legal-for-trade applications.
- Accuracy class: up to C6
- Max. capacity: up to 500 kg
A Proven Sulotion for Weighing Large Loads
Type Z7A Load Cells: Reliable Weighing up to 10 Metric Tons with Accuracy Class C3
The Z7A load cells are perfectly suited for use in tank weighers and batching scales as well as for level monitoring applications.
Due to their 6-wire configuration, they provide precise measurement results of up to accuracy class C3, even with a maximum capacity as high as 10 metric tons (in compliance with OIML R60).
The robust Z7A load cells allow for easy integration owing to their large measuring body and ensure the stability required during operation. In addition, explosion proof IECEx-ATEX designs are (optionally) available.
- Accuracy classes: D1, C3
- Degree of protection: IP67
- Maximum capacity: 500 kg to 10 metric tons
The Ideal Load Cell for Any Application- Precise and Robust
Type HLC Load Cells: Robust Weighing up to Accuracy Class C6
HLC load cells are perfectly suited for use with any type of tank, batching or platform scales as well as for level monitoring - and are used by market leaders. Their 6-wire configuration allows for precise measurement results up to accuracy class C6 per OIML R60. The particularly robust HLC load cells are available in standard dimensions and can be easily integrated and quickly adapted to the required maximum capacities ranging from 110 kg to 10 tons. In addition, versions with IP69K degree of protection and explosion proof IECEx-ATEX designs are available.
- Accuracy class: up to C6
- Degrees of protection: IP68 (100h/1m) and IP69K
- Maximum capacities: 110 kg to 10 tons
The Flexible All-Rounder for Industrial Weighing
The HLCM Weighing Module: Precise Weighing up to C3 Accuracy Class
The HLCM weighing module comes with HBM’s high-quality series HLCB load cell and allows precise weighing up to C3 accuracy class. It offers a broad range of maximum capacities ranging from 110 kilos to 4.4 tons and is ideally suited to be used in tank weighing, level measurement, and batching processes in the food and building materials industries. The HLCM has an integrated stay rod and anti-liftoff device and thus, ensures an outstanding stability of tanks and silos, even in case of strong lateral forces.
The weighing module comes with a self-centering rocker pin that ensures optimal force application and allows immediate use without needing calibration. Robust galvanized or stainless-steel versions are available to ensure chemical resistance and to withstand overloads of up to twice its capacity. An explosion-proof IECEx/ATEX version of the module, with connection cables from a highly resistant braided wire, facilitates deployment in even more demanding applications. The HLCM weighing module is maintenance-free and can be easily integrated because of the pre-assembled load cell and standard boreholes.
- Accuracy class: up to C3
- Maximum capacity: 110 kg to 4.4 t
- Height: max. 125.3 mm
Canister Load Cells
The Robust Load Cell for All Heavy Loads
Type C16A Self-Restoring Load Cell: Reliable Weighing up to 400 Tons
The C16 rocker pin load cells ensure optimal force application, are especially robust and allow for precise weighing up to a maximum capacity, ranging from 20 to 400 tons—and an accuracy class up to C5 per OIML R60. They are also suitable for use in harsh environments, for example, in weighbridges for road or rail vehicles or for level measurement in silos. In addition, C16A load cells with IP 69K degree of protection and explosion proof IECEx-ATEX design are also available. A rotation stop, Ooervoltage protection, and robust cable variants offer additional protection.
- Accuracy class: up to C5
- Maximum capacity: 20 to 400 tons
- Degrees of protection: IP68 and IP69K
C16/M Weigh module
Whether for building industry tanks, coal bunkers or tanks for liquids and gases, the C16 weigh module has the specific properties required and is available for all applications.
All the weighing modules, whether galvanized or made of stainless steel, are fitted with integrated stay rods to absorb the horizontal forces, such as typically occur with wind loads. Anti-liftoff devices are included in the design as an accessory and can be easily fitted by the user when required.
The metrological heart of the module is the C16 selfrestoring pendulum load cell, which is available in various versions.
Special optional features of C16 weighing modules:
- Accuracy class D1, C3 under OIML
- IECEx/ATEX zone 1/21 or zone 2/21
- FM approval (explosion protection for the USA)
- Overvoltage protection
The weighing modules are available with maximum capacities ranging from 20 t to 200 t. This allows tanks of up to approximately 400t, to be constructed and, subject to the design, also made legal for trade.
Versatile and Robust
C2 and C2A Load Cells: Universal Compression Load Cells
Proven useful in tens of thousands of applications, the C2 series load cells provide a reliable and accurate weighing of loads ranging between 50 kg and 50 t. Applications can be found in all branches of industry where tough and robust load cells are required. Some examples of their application include silo and ladle weighing, batching scales, platform scales, or lifter scales (with pulleys).
The C2A version of the load cells (available with a maximum capacity of 1 t, 2 t, 5 t, and 10 t) is legal for trade in the Classes D1, D3, and C4, and it can also be used across all applications where goods are sold by weight.
- Maximum capacity: 50 kg, 100 kg, 200 kg, 500 kg, 1 t, 2 t, 5 t, 10 t, 20 t, 50 t
- Principle of measurement: Strain-gauge full bridge in 6-wire configuration
- Version: Compression load
- Degree of protection: IP67
Ring Torsion Load Cell
Outstanding Weighing Technology for Large Loads
Ring Torsion Load Cells: Precise Weighing up to 470 Tons
RTN ring torsion load cells are available for a wide range of maximum capacities (1 t—470 t). All versions are compact and, at the same time, extremely robust. These properties and their superior degree of protection (up to IP 68/IP 69K) make them ideal for a wide range of container weighing applications, use in large platform scales, and the construction of vehicle scales – even in unfavorable environmental conditions.
HBM’s RTN load cells are extremely precise and minimize the influence of lateral load application with their unique ring-shaped strain gauges. Their high input resistance and low power consumption enable the use of battery-powered evaluation units for taking measurements.
Numerous special versions such as IECEx-ATEX or temperature-resistant versions (up to 110 °C) are available, and different cable lengths and cable types can be configured. A new version with an M12 connector is also available as an option for variants with accuracy class 0.05.
- Maximum capacities: 0…1 t to 0…470 t
- HBM accuracy class: up to C3
- Degree of protection: IP 68 (optional: IP68/IP 69K)
RTN/M Weigh Module
The RTN weighing module is designed to be easy to mount reducing assembly time and costs. The module provides all the functions needed for process measurement applications and gravimetric level measurement and is equipped with a Rubber-metal Bearing or a Pendulum Bearing.
There are two different variations for introducing the load depending on the application: rubber-metal bearings [RTN / M2(L)A] are available for balancing horizontal movements and pendulum bearings [RTN / M2(L)B] are intended for attaining maximum accuracy with very small loads.
All RTN weighing modules are delivered with a load cell dummy because they are often used in harsh industrial environments that can damage the extremely precise transducer. This allows users to use the dummy cell for positioning and substitute it with the actual weighing module when the system is operational.
The basic configuration of the RTN includes an integrated anti-lift-off device and integrated horizontal stops. An optional stay rod for the weighing system is also available from HBM. All HBM modules have been designed for legal-for-trade applications and comply with WELMEC 2.4 requirements (European Cooperation in legal Metrology).
Tension / Compression Load Cells
Tension and compression load cells from HBM are especially suitable for use in tank weighing, plant engineering and process weighing.
Approvals are available for installation in scales that are subject to weights and measures legislation or used in potentially explosive atmospheres, e.g. from the German National Metrology Institute (PTB). Certificates for worldwide use are available as well.
Precise Weighing of Suspended Tanks in Harsh Enviroments
RSCC Tension Load Cell - Weigh up to 5 t With an Accuracy Class of C3
The RSCC tension load cell is ideal for use in static and quasi-static weighing tasks; for instance, for the gravimetric level measurement of suspended tanks as well as for conveyor, batching, and hybrid scales. It is available in seven maximum capacities, which range from 50 kg to 5 t, thus covering a very broad range. Owing to its C3 accuracy class and proven HBM strain-gauge technology, the RSCC provides precise measurement results. A test certificate confirms that it has been approved for use in legal-for-trade applications.
The tension load cell is the optimal solution for use in harsh industrial environments due to its high IP68 degree of protection and has become the standard in weighing tasks in concrete mixing plants. The connection cable can be permanently protected by a connection adapter for cable protection systems, which is available as an option for the tension load cell. All the load cells of the RSCC series are hermetically encapsulated and have a robust, stainless-steel measuring body that enables them to permanently withstand humid and harsh environments. An IECEx/ATEX version of the RSCC is also available for safe use in potentially explosive atmospheres such as in mills and in the chemical industry.
- Accuracy class: C3
- Capacity: 50 kg to 5 t
- Degree of protection: IP68
- Principle of measurement: Strain-gauge full bridge in 6-wire configuration
- Version: Tension load cell
Z16A Tension Load Cell
Rugged load cell for precise weighing of suspended loads
With the Z16A tension load cell, HBM offers a unique solution for weighing suspended loads. Applications include gravimetric level measurements or batching with attached process containers.
Made of stainless steel, the Z16A tension load cell is available for maximum capacities of 7.5 and 15 metric tons. Two different versions feature accuracy class D1 and C3 according to OIML R60. The Z16A is also hermetically encapsulated and achieves degree of protection IP68/IP69K, which allows for use in damp environments.
Due to the sophisticated way in which force is applied, the Z16A is ideally suited for suspended installation in container weighers and in conveyor, batching and hybrid weighers. The load cell is EMC-tested in accordance with OIML R60 (2006) and is able to withstand loading of up to 10 V/m.
The optionally available M36x3 adapter for the Z16A can be used for easy mechanical integration. Knuckle eyes are also available as an alternative. Different legal-for-trade cable lengths are available in the 6-wire configuration. This flexibility reduces the cost of installation without affecting the class accuracy of the load cell.
Read more
Ideal for Use in Lifter Scales in Harsh Enviroments
U2A Legal-For-Trade Tension/Compression Load Cell
The U2A load cell has proven to be useful in thousands of applications and is available with maximum capacities ranging between 50 kg and 20 t. The variants with 500 kg, 1 t, 2 t, and 5 t maximum capacity meet the D1 accuracy class. Additionally, the U2A load cell is available with other maximum capacities and accuracy classes (0.1 and 0.2).
Compliance with the D1 accuracy class allows utilization in Class III scales with a resolution of up to 1,000 divisions in compliance with OIML R60. These can, for example, include suspended tanks, conveyor or batching scales, or hybrid scales. Another major field of application is found in gravimetric level measurement.
- Accuracy classes: D1, 0.1 %, 0.2 % (depending on the maximum capacity)
- Maximum capacity: 50 kg / 100 kg / 200 kg / 500 kg / 1 t/ 2 t / 5 t / 10 t /20 t
- Principle of measurement: Strain-gauge full bridge in 6-wire configuration
- Version: Tension/compression load; preferred direction: Tension
- Degree of protection: IP67
Weighing Electronics & Indicators
Ensuring Simple and Convenient Process Control and Monitoring
AED Digital Transducer Electronics: Turn Analog Load Cells into Digital All-rounders
The AED transducer electronics digitizes the signals from analogue load cells, thus ensuring digital precision in new or existing systems. The installation and commissioning are done quickly and easily due to the bus interfaces and integrated PC software.
- AED measurement chain: Comprising of an AD103C measuring amplifier board, a basic device, and PanelX software
- Accuracy class: 0.01 with a test report for 10000 d, class III according to OIML R76
- Interfaces: RS-232, RS-485, CANopen, DeviceNet, and Profibus DP V1
- Measurement inputs: Two control inputs and four limit outputs
PAD Digital Transducer Electronics
PAD – The Perfect Connection for Analog Transducers and Load Cells to the Digital World
The PAD digital transducer electronics enables passive sensor types to be digitized based on the plug-and-play principle simply by using an M12-plug, thus allowing a cost-effective transition to the digital world. As an "electronics in a tube", the PAD comes in a compact stainless-steel enclosure and is, thus, ideally protected from liquids and dirt. Furthermore, the PAD offers maximum precision - even in demanding environments (up to IP68/IP69K degree of protection).
- Accuracy class: 0.01 with a test report for 6000 d, class III, IIII according to OIML R76
- Interfaces: RS485 (4-wire, full-duplex) and CANopen
Intuitive Software for Weighing Applications
PanelX Weighing Software
PanelX provides you with an innovative user interface that has been specially designed to meet weighing technology requirements, and it allows you to conveniently parameterize your HBK products. Combining a load cell and weighing electronics with the specialized PanelX software enables you to implement a wide range of weighing applications, including highly dynamic filling and check-weighing processes. In practical applications, this often requires digital process acquisition and analysis.
Read more
Clip. Measure. Control.
ClipX – The Precise and Easy-to-Integrate Industrial Signal Conditioner
With an accuracy class of 0.01 and an integrated calibration certificate, the interference-proof signal conditioner ClipX is setting new standards in industrial process control. ClipX adapts to your measurement task, regardless of whether it is used with single- or multiple-channel applications, in manufacturing machines, in test benches or for production monitoring. Owing to the Plug and Play principle, up to six devices can be plugged simultaneously in a modular setup and the measured data can be pre-calculated. Unlike conventional measuring signal conditioners, ClipX does not require a separate head module for direct data processing.
ClipX provides all the latest automation interfaces to perfectly integrate the device into comprehensive control concepts. A particular feature is the intuitive web interface that also enables remote operation, parameterization, and diagnosis.
- Accuracy class: 0.01
- Measurement inputs: Full-bridge and half-bridge strain gauges, piezoresistive transducer, potentiometer, Pt100, current, and voltage
- Interfaces: PROFINET, EtherCAT®,PROFIBUS, Ethernet/IP™*, Modbus-TCP, analog (V/mA,) digital-I/O, and Ethernet (TCP/IP)
- IIoT (Industrial Internet of Things): Remote diagnosis, health monitoring and web integration; integrated OPC-UA server
Weighing Indicators
WE2107
The WE2107 weighing indicator: you can rely on this talented all-rounder to monitor and control your weighing processes. It does not matter whether these are static or dynamic: the WE2107 is at your side.
With first-rate metrological properties and many practical functions that are perfect for incorporating into the industrial weighing process. Because the WE2107 is more than just a weighing indicator: the WE2107 adapts perfectly to your needs, whatever the challenge. So with the WE2107, you will be able to implement many different scale types with just one device:
- platform scales
- counting scales
- truck scales
- container scales
- mobile scales
- batching scales
- filling scales
- …
Weighing Technology Excellence
WTX110: Robust and Legal for Trade Weighing Terminal
The high-performance WTX110 weighing terminal is suited perfectly for static or dynamic filling or dosing tasks. It comes with a robust stainless-steel housing and is IP69K certified. This makes it the ideal choice for industrial and legal for trade weighing applications in harsh environments or for products with strict hygiene requirements. Industries such as food, pharmaceutical, and chemical will especially and greatly benefit from these cutting-edge features.
WTX110-D: Weughung Terminal for Digital Load Cells
WTX110-A can be connected to any analog load cell. WTX110-D enables the connection of digital load cells such as the C16I with RS485 data interface (2- or 4-wire). The high-class TFT color display and intuitive PanelX weighing software allow easy and comfortable on-site operation of the weighing terminal – all at an outstanding price-performance ratio!
WTX120: Industrial and Legal for Trade Weighing Terminal
Any analog load cell based on strain gauges can be connected to the WTX120 industrial and rail-mountable weighing terminal. The weight indicator is ideally suited for filling, dosing and sorting plants and machines and offers everything you'd expect from modern weighing electronics: It can be integrated into standard industrial control systems thanks to industrial Ethernet and Fieldbus interfaces. Push buttons, display and text navigation allow for effortless on-site operation. As an additional benefit, the intuitive HBM weighing software PanelX helps you with start-up or maintenance.
Weighing Accessories
Load Cell Accessories
Conveniently and quickly order your weighing load cell accessories from the HBMshop. You will find more information such as data sheets at the bottom of HBM's website.
