Residual Stress (RY/VY) עיבור (מעוות)
Residual Stress (RY/VY) — חיישנים ומכשירי מדידה של HBK בתחום עיבור (מעוות).
לאתר של HBK (נפתח בלשונית חדשה)
מפרט טכני משותף לסדרה
תכונות שיש לכל דגם בסדרה. מה שמשתנה בין הדגמים מופיע בטבלת הדגמים שלמטה.
טווח על פני הדגמים
הטווח שמכסים דגמי הסדרה יחד – לא הטווח של כל דגם.
| התנגדות נומינלית של מדיד | 120–350 Ω |
|---|
הדגמים בסדרה
עמודה לכל דגם: מה שונה בין דגמי הסדרה.
| פרמטר | 1-RY21-3/120 eli-m-be4a783d0c1ccd402b110a76 | 1-RY61-1.5/120 eli-m-2f8d3e0364b2c7796f9eed22 | 1-RY61-1.5/120K eli-m-a02e81c35166273bdcf63d45 | 1-RY61-1.5/120K3 eli-m-feff53f0fe4e8ce8a990842b | 1-RY61-1.5/120M eli-m-bed555bf1cd2353092b846e0 | 1-RY61-1.5/120R eli-m-ca6535de8cbb7f8e137559c6 | 1-RY61-1.5/120R3 eli-m-e2ffc105c404f23fce68e7c7 | 1-RY61-1.5/120S eli-m-19e2f13c11f634146acfff6d | 1-RY61-1.5/350M eli-m-6d60334697c3a98e0f0d6813 | 1-RY61-3.2/120S eli-m-88c6b10d080f7ad2dbb4be34 | 1-RY67-1.5/120R eli-m-7f0950455f5f104334536cc2 | 1-VY61-1.5/120S eli-m-3b1d77d8caa2454ecb32487d | 1-VY67-1.5/120S eli-m-d103d50c599ec9c5d99647d3 | 1-VY68-1.5/120S eli-m-49672af3987eec02a84c0c56 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| התנגדות נומינלית של מדיד | 120 Ω | 120 Ω | 120 Ω | 120 Ω | 120 Ω | 120 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 120 Ω | 120 Ω | 120 Ω | 120 Ω |
| פרטי ממשק ואות לפי המקור | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown |
| בסיס הגדרת לינאריות | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. |
| בסיס הגדרת חזרתיות | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. |
| נתון טכני לפי גודל ובסיס במקור | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Bondable (adhesive pre-applied) | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Solder tabs with strain relief; Embeddable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Plastic (65 ppm/K; 36.1 ppm/°F); Solder tabs with strain relief; Embeddable |
| סטטוס | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל |
