TU (T Rosettes) עיבור (מעוות)
TU (T Rosettes) — חיישנים ומכשירי מדידה של HBK בתחום עיבור (מעוות).
לאתר של HBK (נפתח בלשונית חדשה)
מפרט טכני משותף לסדרה
תכונות שיש לכל דגם בסדרה. מה שמשתנה בין הדגמים מופיע בטבלת הדגמים שלמטה.
טווח על פני הדגמים
הטווח שמכסים דגמי הסדרה יחד – לא הטווח של כל דגם.
| התנגדות נומינלית של מדיד | 350–5000 Ω |
|---|
הדגמים בסדרה
עמודה לכל דגם: מה שונה בין דגמי הסדרה.
| פרמטר | 1-TU21K1.6/1K0_E eli-m-e4217a899085db8179b6219b | 1-TU21K1.6/5K0_E eli-m-b8b9ecc56aac0cc573b9d10a | 1-TU21K3/350_E eli-m-36ae75c95597e755777ca8d5 | 1-TU21K3/5K0_E eli-m-c88186b69e8115b7eeed7d91 | 1-TU21S1.6/1K0_E eli-m-d9d6617559123ebb8024c9dd | 1-TU31S5.1/1K0_E eli-m-fc5869e2d2e25628495b85b1 | K-TU21K1.6/1K0BE eli-m-d7c975b12c4bf734cdf90a34 | K-TU21K1.6/1K0LE eli-m-7d85c41f08cf0e0daf49a619 | K-TU23K1.6/1K0_E eli-m-d1b1c7f5ceada05579438eca | K-TU23K1.6/1K0BE eli-m-b5c24549a01a8996036a3527 | K-TU23K1.6/1K0LE eli-m-867d54be3851cf15d06cf6c8 | K-TU23K1.6/5K0_E eli-m-d91f075fa6afb50b5520924c | K-TU31K5.1/1K0_E eli-m-2e8d6b36f424e8b565522d19 | K-TU31K5.1/1K0BE eli-m-76c142304cfbcf9d31b896a4 | K-TU31K5.1/1K0LE eli-m-8b456def16f1f6ca247182b9 | K-TU33K5.1/1K0_E eli-m-d522d587cd848569e67873cc | K-TU33K5.1/1K0BE eli-m-382cea3ea2a96aa75e3d1a44 | K-TU33K5.1/1K0LE eli-m-d974f998cb1e2c2d4694eb21 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| נתון טכני לפי גודל ובסיס במקור | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable (adhesive pre-applied) | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable (adhesive pre-applied) | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Solder tabs with strain relief; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable (adhesive pre-applied) | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable (adhesive pre-applied) | Strain gauge; T rosette; Cr-Ni alloy (ca. 2.2); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable |
| התנגדות נומינלית של מדיד | 1000 Ω | 5000 Ω | 350 Ω | 5000 Ω | 1000 Ω | 1000 Ω | 1000 Ω | 1000 Ω | 1000 Ω | 1000 Ω | 1000 Ω | 5000 Ω | 1000 Ω | 1000 Ω | 1000 Ω | 1000 Ω | 1000 Ω | 1000 Ω |
| בסיס הגדרת לינאריות | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. |
| בסיס הגדרת חזרתיות | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. |
| פרטי ממשק ואות לפי המקור | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown |
| סטטוס | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל |
