XY1/2/4 (Torsion/Shear) עיבור (מעוות)
XY1/2/4 (Torsion/Shear) — חיישנים ומכשירי מדידה של HBK בתחום עיבור (מעוות).
לאתר של HBK (נפתח בלשונית חדשה)
מפרט טכני משותף לסדרה
תכונות שיש לכל דגם בסדרה. מה שמשתנה בין הדגמים מופיע בטבלת הדגמים שלמטה.
טווח על פני הדגמים
הטווח שמכסים דגמי הסדרה יחד – לא הטווח של כל דגם.
| אורך נשא המדיד | 6.5–17.5 mm |
|---|---|
| מידה לפי סימון בשרטוט | 0.6–17.5 mm |
| התנגדות נומינלית של מדיד | 120–700 Ω |
| רוחב נשא המדיד | 4–12.7 mm |
| רוחב רשת מדיד | 1.5–10 mm |
| אורך רשת מדיד | 0.6–6 mm |
| מתח עירור מרבי | 1.5–19 V |
הדגמים בסדרה
עמודה לכל דגם: מה שונה בין דגמי הסדרה.
| פרמטר | 1-XY11-1.5/350_E eli-m-9dcedfaa9eaeb281279b4554 | 1-XY11-3/350_E eli-m-ff7488879334e5e814e22dd1 | 1-XY11-6/350_E eli-m-fe8374937f0f454730962a6d | 1-XY13-1.5/350_E eli-m-88d5a53a6b686cd81860c0fc | 1-XY13-3/350_E eli-m-a1372164225f6cfce4ca38bd | 1-XY13-6/350_E eli-m-c0a5ce92c79090b615f2abea | 1-XY15-1.5/350_E eli-m-af9dc135da15de6e1ebbf83f | 1-XY15-3/350_E eli-m-e0b2b836e6e6835370b848c4 | 1-XY15-6/350_E eli-m-da0ad0094302a471cae54d5e | 1-XY16-3/350_E eli-m-ea18bf8f87c57612652ac4c8 | 1-XY16-6/350_E eli-m-94078c62cb9af9482b14f3bf | 1-XY17-3/350_E eli-m-b30c86ee4c6149c9eb6a6687 | 1-XY17-6/350_E eli-m-55592beddd5e773b9b96d572 | 1-XY18-3/350_E eli-m-db080e2253f9b3d7d2e96303 | 1-XY18-6/350_E eli-m-ebbaca463b12bf44d97b6753 | 1-XY21-0.6/120 eli-m-f1f34f302dbebee58e6eccdf | 1-XY21-1.5/120 eli-m-b8a242d1d29884b5b6ce816a | 1-XY21-1.5/350 eli-m-ba42e4c3a4813a10c3ad2f5a | 1-XY21-3/120 eli-m-dd5cb4ad2d342024539d4a27 | 1-XY21-3/350 eli-m-cf6cef0da4443fd12dafe950 | 1-XY21-3/700 eli-m-389149a786d9a001a03ff838 | 1-XY21-6/120 eli-m-956d42b9f2a9bfb9fd0455c4 | 1-XY21-6/350 eli-m-e3369476c47d185d36f5abe2 | 1-XY21-6/700 eli-m-9088c517491806d246af3159 | 1-XY23-0.6/120 eli-m-4325753c7ccd0a4a5567d8ca | 1-XY23-1.5/120 eli-m-59ce33e618668255ce2874bd | 1-XY23-1.5/350 eli-m-878479142d3a5b9e148fcdc9 | 1-XY23-3/120 eli-m-a733abb80b734314568bb06e | 1-XY23-3/350 eli-m-e3183364e4e6560caeb609d2 | 1-XY23-3/700 eli-m-98d82cc27fbdfea67702b71e | 1-XY23-6/120 eli-m-c705fdbfa624f4c2cc26fc42 | 1-XY23-6/350 eli-m-ce72bc7a6153c9227b7f0416 | 1-XY23-6/700 eli-m-ed3ab3d3d7dfd6553b4c4779 | 1-XY25-0.6/120 eli-m-99d0d4a154e6e609feae3e19 | 1-XY25-1.5/120 eli-m-e41ce5e216f8bed0c46ae107 | 1-XY25-1.5/350 eli-m-eee77dd769e32a95bd217067 | 1-XY25-3/120 eli-m-39a809aaafe4fcd8573e0ca1 | 1-XY25-3/350 eli-m-8a683a99040c39f48ff2f22e | 1-XY25-3/700 eli-m-e21b99765c0cd7bb4680f014 | 1-XY25-6/120 eli-m-c4251aa17240d26424e304a4 | 1-XY25-6/350 eli-m-3b583abddb047ce68745eefd | 1-XY25-6/700 eli-m-35c9d8a831e92dfede1b373d | 1-XY26-1.5/120 eli-m-09367b3fcde0b105035256c1 | 1-XY26-3/120 eli-m-4da79e8e65921da139209ba4 | 1-XY26-3/350 eli-m-2bf79e606d2d168ea65cb5b4 | 1-XY26-6/120 eli-m-9f2a679440d574dd1dfa1f16 | 1-XY26-6/350 eli-m-4f04fd7c871adf838aa88879 | 1-XY26-6/700 eli-m-b40e9fcc060800dcd3cf35bd | 1-XY27-1.5/120 eli-m-dc582d8977d2d5e14107af48 | 1-XY27-3/120 eli-m-d8df5f7ff83c7b018d4befee | 1-XY27-3/350 eli-m-8f3287261034e9650da858a2 | 1-XY27-6/120 eli-m-c1bddc4ab89ef9f5e6b351b4 | 1-XY27-6/350 eli-m-10e4bc0a5cf2698370749488 | 1-XY27-6/700 eli-m-ff7454a683ffada45274e621 | 1-XY28-1.5/120 eli-m-4ac44047ddfa58231c398323 | 1-XY28-3/120 eli-m-0a0314d9889d26fd8f61da14 | 1-XY28-3/350 eli-m-178a0cfacd7f65d93b50ce89 | 1-XY28-6/120 eli-m-88d4562c6167293c048d8a18 | 1-XY28-6/350 eli-m-defb673c8f9e2a88be1f14b8 | 1-XY28-6/700 eli-m-885e530af99d52007108828a | 1-XY41-0.6/120 eli-m-34009c6ffc0bb4bae4e8ef2c | 1-XY41-1.5/120 eli-m-3f03b0fca48c648c620b5846 | 1-XY41-1.5/350 eli-m-d9c1c5151f041a40327a0779 | 1-XY41-3/120 eli-m-cad46b1a38b6b3e62e38530c | 1-XY41-3/350 eli-m-aaf00c7a9a97f55199144fba | 1-XY41-3/350HE eli-m-b0eaadfe1aad0d1b78c6640b | 1-XY41-3/700 eli-m-6859d65d175a65efca629b39 | 1-XY41-6/120 eli-m-c1dfd51243e6c0f114aa197e | 1-XY41-6/350 eli-m-a1222993f556940e0187b30a | 1-XY41-6/350HE eli-m-09a351caa998806e9a8d0724 | 1-XY41-6/700 eli-m-a1b083f1759d24c951747d32 | 1-XY43-0.6/120 eli-m-e42c29497aa8dc141ccaa17c | 1-XY43-1.5/120 eli-m-da09adc09a1967e8276fb158 | 1-XY43-1.5/350 eli-m-48908150e4c10c719cc9ac99 | 1-XY43-3/120 eli-m-758c29e53c60c3a175b2ce09 | 1-XY43-3/350 eli-m-a2cca1faea09555cc1b0ab10 | 1-XY43-3/700 eli-m-545fc04399abf5e3f9b87c27 | 1-XY43-6/120 eli-m-c87cf4e6e9d6fe4c842fb3f1 | 1-XY43-6/350 eli-m-e2d764af9a562442f2a4b7ce | 1-XY43-6/700 eli-m-4bed55f42d368f6e40d36d30 | 1-XY45-0.6/120 eli-m-59cd63160cde6c5f1ebff024 | 1-XY45-1.5/120 eli-m-c0764af97a737ed2dc8ac48d | 1-XY45-1.5/350 eli-m-d26bb98fb92a9467c078aa6e | 1-XY45-3/120 eli-m-e85fdb9ed2ea0da53d52a293 | 1-XY45-3/350 eli-m-161e4e20584b2490ec8dabed | 1-XY45-3/700 eli-m-7364dd9ba2a8f6a5f815ebd2 | 1-XY45-6/120 eli-m-6fcca73817f479af87c1bf77 | 1-XY45-6/350 eli-m-05c41542dfdeb6b949fc844e | 1-XY45-6/700 eli-m-5875c6512b2d66262a37b426 | 1-XY46-1.5/120 eli-m-ec74de872aca4ef4e670d4c7 | 1-XY46-3/120 eli-m-d3b1ea37571e51e7f3752c5a | 1-XY46-3/350 eli-m-0c981c5a2019152a40be00c8 | 1-XY46-3/700 eli-m-47d6efbdd89223549313e7a8 | 1-XY46-6/120 eli-m-b7509d080e88bf85e5ec91c5 | 1-XY46-6/350 eli-m-963bc022cc5fae0e53a05dca | 1-XY46-6/700 eli-m-8e949be412dcfce58b1b6d39 | 1-XY47-1.5/120 eli-m-c9ac80538e25c6eb82395699 | 1-XY47-3/120 eli-m-342eb14c9f9b9c5629c1680c | 1-XY47-3/350 eli-m-82e613619fa58509290854dc | 1-XY47-3/700 eli-m-9fa81e1c36dfb2c32eae87ca | 1-XY47-6/120 eli-m-8026875e4058fd3c18e42a0b | 1-XY47-6/350 eli-m-c8d0c8c08d339784c20f4b23 | 1-XY47-6/700 eli-m-0cd28fde20083552db271efa | 1-XY48-1.5/120 eli-m-bb982beff19fd5f25b217507 | 1-XY48-3/120 eli-m-8858d69ff1fd5942c340d416 | 1-XY48-3/350 eli-m-eb07540d2e16a1d11369136c | 1-XY48-3/700 eli-m-7ea2246a40e6e30ac60e7741 | 1-XY48-6/120 eli-m-cb9930d866cf6ccfd2b208b4 | 1-XY48-6/350 eli-m-83191db8ffe54fe6e2279961 | 1-XY48-6/700 eli-m-d2b2b0c09f847b635f1e615e |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| אורך נשא המדיד | 7.8 mm | 10 mm | 12.3 mm | 7.8 mm | 10 mm | 12.3 mm | 7.8 mm | 10 mm | לא צוין | 10 mm | 12.3 mm | 10 mm | 12.3 mm | 10 mm | 12.3 mm | 7.5 mm | 6.8 mm | 7.4 mm | 11.2 mm | 11.2 mm | 11.2 mm | 17.5 mm | 17.5 mm | 17.5 mm | 7.5 mm | 6.8 mm | 7.4 mm | 11.2 mm | 11.2 mm | 11.2 mm | 17.5 mm | 17.5 mm | 17.5 mm | 7.5 mm | 6.8 mm | 7.4 mm | 11.2 mm | 11.2 mm | 11.2 mm | 17.5 mm | 17.5 mm | 17.5 mm | 6.8 mm | 11.2 mm | 11.2 mm | 17.5 mm | 17.5 mm | 17.5 mm | 6.8 mm | 11.2 mm | 11.2 mm | 17.5 mm | 17.5 mm | 17.5 mm | 6.8 mm | 11.2 mm | 11.2 mm | 17.5 mm | 17.5 mm | 17.5 mm | 6.5 mm | 7.5 mm | 7.5 mm | 11 mm | 11 mm | 11 mm | 11 mm | 16 mm | 16 mm | 16 mm | 16 mm | 6.5 mm | 7.5 mm | 7.5 mm | 11 mm | 11 mm | 11 mm | 16 mm | 16 mm | 16 mm | 6.5 mm | 7.5 mm | 7.5 mm | 11 mm | 11 mm | 11 mm | 16 mm | 16 mm | 16 mm | 7.5 mm | 11 mm | 11 mm | 11 mm | 16 mm | 16 mm | 16 mm | 7.5 mm | 11 mm | 11 mm | 11 mm | 16 mm | 16 mm | 16 mm | 7.5 mm | 11 mm | 11 mm | 11 mm | 16 mm | 16 mm | 16 mm |
| בסיס הגדרת לינאריות | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. | Use the exact HBK gauge factor, transverse sensitivity and batch calibration values supplied with the ordering code. |
| חיבור באמצעות לשוניות הלחמה או כבל | LS 7 | LS 5 | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | LS 7 | LS 5 | LS 4 | LS 5 | LS 4 | LS 5 | Integrated solder tabs | Integrated solder tabs | LS 4 | Leads | LS 7 | LS 7 | Leads | LS 4 | Leads | LS 4 | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | Leads | LS 4 | LS 4 | LS 4 | LS 7 | LS 4 | Leads | Leads | LS 4 | Leads | Leads | LS 4 | LS 4 | LS 4 | Leads | LS 4 | LS 7 | Leads | LS 4 | LS 4 | LS 4 | Leads | LS 7 | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | LS 7 | Pre-wired (TPE-insulated ribbon cable) | Integrated solder tabs | LS 4 | LS 4 | Leads | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | LS 7 | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | LS 7 | LS 7 | LS7 | Integrated solder tabs | LS 7 | LS 7 | LS 4 | Integrated solder tabs | Integrated solder tabs | LS 7 | Integrated solder tabs | Integrated solder tabs | Integrated solder tabs | LS 4 | Integrated solder tabs | Integrated solder tabs | LS 7 | LS 7 | Integrated solder tabs | Integrated solder tabs | LS 4 | LS 4 | Integrated solder tabs | LS 7 | Integrated solder tabs | Integrated solder tabs | LS 7 | Integrated solder tabs | LS 4 | Integrated solder tabs |
| נתון טכני לפי גודל ובסיס במקור | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Pre-wired (TPE-insulated ribbon cable); Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Austenitic steel (16 ppm/K; 8.9 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Silica / composite (0,5 ppm/K; 0.3 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Titanium / gray cast iron (9 ppm/K; 5.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; Shear/torsion; Constantan (ca 2.0); Standard (up to 200°C); Plastic (65 ppm/K; 36.1 ppm/°F); Integrated solder tabs; Bondable |
| בסיס הגדרת חזרתיות | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. | No unsupported standalone repeatability is inferred; installed repeatability is verified after bonding and shunt calibration. |
| מידה לפי סימון בשרטוט | 4.9 mm | 6.9 mm | לא צוין | לא צוין | לא צוין | לא צוין | 4.9 mm | 3 mm | 11.7 mm | 4.9 mm | 12.3 mm | 6.9 mm | 12.3 mm | 10 mm | 12.3 mm | לא צוין | 1.5 mm | 2.5 mm | 5.3 mm | 5.3 mm | לא צוין | 12.7 mm | 8 mm | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | 0.6 mm | 1.5 mm | 7.4 mm | 9.5 mm | 5.3 mm | 11.2 mm | 12.7 mm | 17.5 mm | 6 mm | 1.5 mm | 3.7 mm | 5.3 mm | 8 mm | 8 mm | 17.5 mm | 6.8 mm | 5.3 mm | 4.2 mm | 6 mm | 8 mm | 17.5 mm | 6.8 mm | 5.3 mm | 5.3 mm | 12.7 mm | 10 mm | 7.8 mm | 0.6 mm | 1.8 mm | 4.5 mm | 8 mm | 4.2 mm | לא צוין | 3 mm | 16 mm | 6 mm | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | 5.6 mm | לא צוין | לא צוין | לא צוין | לא צוין | 1.6 mm | 3.1 mm | 2.1 mm | 8 mm | 5.6 mm | 5.6 mm | 6 mm | 10 mm | 6.1 mm | 1.5 mm | 5.4 mm | 3 mm | 5.6 mm | 12.2 mm | 6 mm | 9.9 mm | 4.6 mm | 3 mm | 5.6 mm | 5.6 mm | 16 mm | 16 mm | 6.1 mm | 3.1 mm | 5.4 mm | 11 mm | 3 mm | 12.2 mm | 12.2 mm | 16 mm |
| התנגדות נומינלית של מדיד | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 350 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 120 Ω | 350 Ω | 700 Ω | 120 Ω | 350 Ω | 700 Ω |
| רוחב נשא המדיד | 4.9 mm | 6.9 mm | 11.7 mm | 4.9 mm | 6.9 mm | 11.7 mm | 4.9 mm | 6.9 mm | לא צוין | 6.9 mm | 11.7 mm | 6.9 mm | 11.7 mm | 6.9 mm | 11.7 mm | 4 mm | 4.5 mm | 4.5 mm | 9.5 mm | 9.5 mm | 9.5 mm | 12.7 mm | 12.7 mm | 12.7 mm | 4 mm | 4.5 mm | 4.5 mm | 9.5 mm | 9.5 mm | 9.5 mm | 12.7 mm | 12.7 mm | 12.7 mm | 4 mm | 4.5 mm | 4.5 mm | 9.5 mm | 9.5 mm | 9.5 mm | 12.7 mm | 12.7 mm | 12.7 mm | 4.5 mm | 9.5 mm | 9.5 mm | 12.7 mm | 12.7 mm | 12.7 mm | 4.5 mm | 9.5 mm | 9.5 mm | 12.7 mm | 12.7 mm | 12.7 mm | 4.5 mm | 9.5 mm | 9.5 mm | 12.7 mm | 12.7 mm | 12.7 mm | 4.6 mm | 4.6 mm | 4.5 mm | 8 mm | 8 mm | 8 mm | 8 mm | 12.2 mm | 12.2 mm | 12.2 mm | 12.2 mm | 4.6 mm | 4.6 mm | 4.5 mm | 8 mm | 8 mm | 8 mm | 12.2 mm | 12.2 mm | 12.2 mm | 4.6 mm | 4.6 mm | 4.5 mm | 8 mm | 8 mm | 8 mm | 12.2 mm | 12.2 mm | 12.2 mm | 4.6 mm | 8 mm | 8 mm | 8 mm | 12.2 mm | 12.2 mm | 12.2 mm | 4.6 mm | 8 mm | 8 mm | 8 mm | 12.2 mm | 12.2 mm | 12.2 mm | 4.6 mm | 8 mm | 8 mm | 8 mm | 12.2 mm | 12.2 mm | 12.2 mm |
| רוחב רשת מדיד | 1.5 mm | 4.4 mm | 6.5 mm | 2.2 mm | 4.4 mm | 6.5 mm | 2.2 mm | 4.4 mm | לא צוין | 4.4 mm | 6.5 mm | 4.4 mm | 6.5 mm | 4.4 mm | 6.5 mm | 2.2 mm | 1.7 mm | 2.2 mm | 3.7 mm | 4.2 mm | 4 mm | 8 mm | 8 mm | 7.8 mm | 2.2 mm | 1.7 mm | 2.2 mm | 3.7 mm | 4.2 mm | 4 mm | 8 mm | 8 mm | 7.8 mm | 2.2 mm | 1.7 mm | 2.2 mm | 3.7 mm | 4.2 mm | 4 mm | 8 mm | 8 mm | 7.8 mm | 1.7 mm | 3.7 mm | 4.2 mm | 8 mm | 8 mm | 7.8 mm | 1.7 mm | 3.7 mm | 4.2 mm | 8 mm | 8 mm | 7.8 mm | 1.7 mm | 3.7 mm | 4.2 mm | 8 mm | 8 mm | 7.8 mm | 2.2 mm | 1.8 mm | 2.1 mm | 3 mm | 4.2 mm | 5.6 mm | 4.2 mm | 6 mm | 6 mm | 10 mm | 6.1 mm | 2.2 mm | 1.8 mm | 2.1 mm | 3 mm | 4.2 mm | 4.2 mm | 6 mm | 6 mm | 6.1 mm | 2.2 mm | 1.8 mm | 2.1 mm | 3 mm | 4.2 mm | 4.2 mm | 6 mm | 6 mm | 6.1 mm | 1.8 mm | 3 mm | 4.2 mm | 4.2 mm | 6 mm | 6 mm | 6.1 mm | 1.8 mm | 3 mm | 4.2 mm | 4.2 mm | 6 mm | 6 mm | 6.1 mm | 1.8 mm | 3 mm | 4.2 mm | 4.2 mm | 6 mm | 6 mm | 6.1 mm |
| אורך רשת מדיד | 1.5 mm | 3 mm | 6 mm | 1.5 mm | 3 mm | 6 mm | 1.5 mm | 3 mm | לא צוין | 3 mm | 6 mm | 3 mm | 6 mm | 3 mm | 6 mm | 0.6 mm | 1.5 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 0.6 mm | 1.5 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 0.6 mm | 1.5 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 1.5 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 1.5 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 1.5 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 0.6 mm | 1.5 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 6 mm | 0.6 mm | 1.5 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 0.6 mm | 1.5 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm | 1.5 mm | 3 mm | 3 mm | 3 mm | 6 mm | 6 mm | 6 mm |
| פרטי ממשק ואות לפי המקור | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown |
| מספר יחידות באריזה | 5 | 5 | לא צוין | לא צוין | לא צוין | לא צוין | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | לא צוין | 5 | 5 | 5 | 5 | לא צוין | 5 | 5 | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | לא צוין | 5 | 5 | 5 | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | 5 | לא צוין | לא צוין | לא צוין | לא צוין | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| מתח עירור מרבי | 3.5 V | 10.5 V | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | 4.5 V | 5 V | 6 V | 10 V | לא צוין | 11 V | 19 V | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | 1.5 V | 2.5 V | 4 V | 5 V | 9.5 V | לא צוין | 13.5 V | 9.5 V | 16 V | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין |
| סטטוס | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל |
