FS65ACC חיישני רעידות ותאוצה
FS65ACC — חיישנים ומכשירי מדידה של HBK בתחום חיישני רעידות ותאוצה.
לאתר של HBK (נפתח בלשונית חדשה)
הדגמים בסדרה
עמודה לכל דגם: מה שונה בין דגמי הסדרה.
| פרמטר | 1-FS65ACC-10/1530 eli-m-ff20609db2818b9b80b6f51b | 1-FS65ACC-10/1540 eli-m-f5d494cf4de2fb1e5134cebd | 1-FS65ACC-10/1550 eli-m-03ca2afa6e8439b66d636563 | 1-FS65ACC-10/1560 eli-m-01b65ba4867e414a923ee58c | 1-FS65ACC-10/1570 eli-m-028abe22c2c33f1992d8e945 | K-FS65ACC eli-m-751fdd95b80ff0bdae696dea |
|---|---|---|---|---|---|---|
| טמפרטורת עבודה | -23–85 °C | -23–85 °C | -23–85 °C | -23–85 °C | -23–85 °C | -23–85 °C |
| בסיס קצב הדגימה | Sensor bandwidth is indexed by HBK; the selected conditioner and DAQ determine digital sample rate. | Sensor bandwidth is indexed by HBK; the selected conditioner and DAQ determine digital sample rate. | Sensor bandwidth is indexed by HBK; the selected conditioner and DAQ determine digital sample rate. | Sensor bandwidth is indexed by HBK; the selected conditioner and DAQ determine digital sample rate. | Sensor bandwidth is indexed by HBK; the selected conditioner and DAQ determine digital sample rate. | Sensor bandwidth is indexed by HBK; the selected conditioner and DAQ determine digital sample rate. |
| מגבלת קצב בגלל קריאת המערכת | True | True | True | True | True | True |
| מספר ערוצי מדידה | 1 | 1 | 1 | 1 | 1 | 1 |
| פרטי ממשק ואות לפי המקור | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown |
| יכולת מדידת תאוצה סטטית DC | False | False | False | False | False | False |
| נתון טכני לפי גודל ובסיס במקור | ±10 g indexed capacity; Uniaxial; General purpose; Center bolt mounting | ±10 g indexed capacity; Uniaxial; General purpose; Center bolt mounting | ±10 g indexed capacity; Uniaxial; General purpose; Center bolt mounting | ±10 g indexed capacity; Uniaxial; General purpose; Center bolt mounting | ±10 g indexed capacity; Uniaxial; General purpose; Center bolt mounting | ±10 g indexed capacity; Uniaxial; General purpose; Center bolt mounting |
| תחום תדרי תגובה | 0–300 Hz | 0–300 Hz | 0–300 Hz | 0–300 Hz | 0–300 Hz | 0–300 Hz |
| מספר צירי מדידה | 1 | 1 | 1 | 1 | 1 | 1 |
| בסיס הגדרת לינאריות | No numeric sensitivity tolerance was exposed for this ordering code in the official index. | No numeric sensitivity tolerance was exposed for this ordering code in the official index. | No numeric sensitivity tolerance was exposed for this ordering code in the official index. | No numeric sensitivity tolerance was exposed for this ordering code in the official index. | No numeric sensitivity tolerance was exposed for this ordering code in the official index. | No numeric sensitivity tolerance was exposed for this ordering code in the official index. |
| בסיס הגדרת חזרתיות | HBK does not publish a separate scalar repeatability for every ordering code; use individual calibration and controlled mounting. | HBK does not publish a separate scalar repeatability for every ordering code; use individual calibration and controlled mounting. | HBK does not publish a separate scalar repeatability for every ordering code; use individual calibration and controlled mounting. | HBK does not publish a separate scalar repeatability for every ordering code; use individual calibration and controlled mounting. | HBK does not publish a separate scalar repeatability for every ordering code; use individual calibration and controlled mounting. | HBK does not publish a separate scalar repeatability for every ordering code; use individual calibration and controlled mounting. |
| יציאת חיישן רעידות | Fiber Bragg Grating; Analogue | Fiber Bragg Grating; Analogue | Fiber Bragg Grating; Analogue | Fiber Bragg Grating; Analogue | Fiber Bragg Grating; Analogue | Fiber Bragg Grating; Analogue |
| רגישות מתח לתאוצה | 59 mV/g | 59 mV/g | 59 mV/g | 59 mV/g | 59 mV/g | 59 mV/g |
| סטטוס | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל |
