P3IC חיישני לחץ
P3IC — חיישנים ומכשירי מדידה של HBK בתחום חיישני לחץ.
לאתר של HBK (נפתח בלשונית חדשה)
הדגמים בסדרה
עמודה לכל דגם: מה שונה בין דגמי הסדרה.
| פרמטר | 1-P3IC/1000BAR eli-m-8120573569ad3c68c254da23 | 1-P3IC/100BAR eli-m-ca93f22721e944b85d4da9d3 | 1-P3IC/10BAR eli-m-51aa27ea93dff6397ac9eb4e | 1-P3IC/2000BAR eli-m-b8bccd98eff13476515fc1be | 1-P3IC/200BAR eli-m-fe6731c00bbb2dfbc58115eb | 1-P3IC/20BAR eli-m-b46fe9872de052770928260d | 1-P3IC/2500BAR eli-m-8eec1df5a5d174bc569c38d5 | 1-P3IC/3000BAR eli-m-592123d14cf875aa99feffff | 1-P3IC/500BAR eli-m-e1877a77d58092d296455dce | 1-P3IC/50BAR eli-m-04b518a472cf54e07b09417a | 1-P3IC/750BAR eli-m-45a695e6e04b9928354a4a64 | 1-P3ICP/1000BAR eli-m-0547ee5304e8cdea3f059b70 | 1-P3ICP/100BAR eli-m-66ad2b063b3da41bec043069 | 1-P3ICP/10BAR eli-m-76a5f6e034991185fae9e04e | 1-P3ICP/2000BAR eli-m-da542d23dcde638560e010a8 | 1-P3ICP/200BAR eli-m-b6f207a0b506c608d3c1cbb2 | 1-P3ICP/20BAR eli-m-e2c5dfd1a9e0440123dcb421 | 1-P3ICP/2500BAR eli-m-7f98e49faaac47438dabd37d | 1-P3ICP/3000BAR eli-m-059fe315a1d8fb9fab59fd76 | 1-P3ICP/500BAR eli-m-95360e1309680346faad3a89 | 1-P3ICP/50BAR eli-m-51597e3235c69898557647fb | 1-P3ICP/750BAR eli-m-ac538766c97a99a459d5f854 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| יציאת חיישן לחץ | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge | Passive strain gauge |
| טמפרטורת עבודה | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C | -40–100 °C |
| בסיס קצב הדגימה | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. | The selected bridge amplifier and DAQ define the digital sample rate. |
| עקרון מדידת לחץ | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure | Absolute pressure |
| דרגת אטימות IP | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 | ip67 |
| פרטי ממשק ואות לפי המקור | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown |
| ייחוס מדידת לחץ | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f | v_9030f6c8e098622f |
| בסיס הגדרת לינאריות | Official indexed accuracy class: 0.1%. | Official indexed accuracy class: 0.15%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.15%. | Official indexed accuracy class: 0.15%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.1%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.1%. | Official indexed accuracy class: 0.1%. | Official indexed accuracy class: 0.15%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.15%. | Official indexed accuracy class: 0.15%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.1%. | Official indexed accuracy class: 0.2%. | Official indexed accuracy class: 0.1%. |
| מחלקת דיוק / שגיאת לחץ | 0.1 % (source basis mandatory) | 0.15 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.15 % (source basis mandatory) | 0.15 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.1 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.1 % (source basis mandatory) | 0.1 % (source basis mandatory) | 0.15 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.15 % (source basis mandatory) | 0.15 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.1 % (source basis mandatory) | 0.2 % (source basis mandatory) | 0.1 % (source basis mandatory) |
| בסיס הגדרת חזרתיות | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. | No unsupported standalone repeatability is inferred; verify the complete installed pressure chain by calibration. |
| טווח לחץ | 0–1000 bar | 0–100 bar | 0–10 bar | 0–2000 bar | 0–200 bar | 0–20 bar | 0–2500 bar | 0–3000 bar | 0–500 bar | 0–50 bar | 0–750 bar | 0–1000 bar | 0–100 bar | 0–10 bar | 0–2000 bar | 0–200 bar | 0–20 bar | 0–2500 bar | 0–3000 bar | 0–500 bar | 0–50 bar | 0–750 bar |
| נתון טכני לפי גודל ובסיס במקור | 0 to 1000 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 100 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 10 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 2000 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 200 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 20 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 2500 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 3000 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 500 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 50 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 750 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Fixed cable | 0 to 1000 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 100 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 10 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 2000 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 200 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 20 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 2500 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 3000 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 500 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 50 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug | 0 to 750 bar nominal; Absolute pressure; Passive strain gauge; Industrial; Plug |
| מגבלת קצב בגלל קריאת המערכת | True | True | True | True | True | True | True | True | True | True | True | True | True | True | True | True | True | True | True | True | True | True |
| טווח לחץ | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין | לא צוין |
| סטטוס | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל | פעיל |
