Type 4189 microphone sets Microphones
Type 4189 microphone sets: sensors and measurement devices by HBK for microphones.
Visit the HBK site (opens in a new tab)
Models in the series
One column per model: what differs between the models of the series.
| Parameter | 4189-A-031 eli-m-8a7a0b4e9af2487c50731011 |
|---|---|
| Microphone polarization | v_fd92f923cc55cf55 |
| Maximum SPL | 134 dB SPL |
| ADC sampling rate | 131072 samples/s |
| Microphone sensitivity | 50 mV/Pa |
| Interfaces | ethernet |
| Sound field | v_8386d113d451ff50 |
| Operating temperature | -30–150 °C |
| Number of measurement channels | 6 |
| Frequency response | 6.3–20000 Hz |
| Microphone diameter | 0.5 inch |
| source_acoustic_standard | IEC 61094 measurement microphone; system class depends on selected set and analyzer configuration |
| A-weighted inherent noise | 14.6 dB(A) |
| quantity_specification | 16.5-134 dB dynamic range for the CCLD set; 6.3 Hz-20 kHz microphone response. |
| source_sampling_rate_basis | LAN-XI 3050-A-060 sample rate; system analysis bandwidth is limited by the microphone to 20 kHz. |
| Status | Active |
