RF (Rosette) Strain
RF (Rosette): sensors and measurement devices by HBK for strain.
Visit the HBK site (opens in a new tab)
Shared technical specifications for the series
Properties every model in the series has. What differs is in the models table below.
Range across models
The span covered by the models of the series together — not the range of each model.
| Gauge resistance | 120–350 Ω |
|---|
Models in the series
One column per model: what differs between the models of the series.
| Parameter | 1-RF91-0.8/120_W eli-m-965244674aeec51559eaefdd | 1-RF91-0.8/120ZE eli-m-914a2a07d4eb9f7de5e1e562 | 1-RF91-1.4/350VE eli-m-fa3b633cd4a1ef06e9067bd4 | 1-RF91-1/120DE eli-m-405c7d2df491c19ebffa8ab9 | 1-RF91-1/120ZE eli-m-f781d024a7973b0fc24f141b | 1-RF93-0.8/120_W eli-m-5e2bdf532ea360f0bf434c6d | 1-RF93-0.8/120ZE eli-m-2c3e3114714b77be522cb921 | 1-RF93-1.4/350VE eli-m-edeaa594554fe14c91c4100e | 1-RF93-1/120ZE eli-m-8a022b5a6e8f2470c23e8075 | 1-RF95-0.8/120_W eli-m-157b7d571ecb93c8eb207956 | 1-RF95-0.8/120ZE eli-m-b77e5cc13280daa0fc987a99 | 1-RF95-1.4/350VE eli-m-a303057e19c68ad54ed1aa99 | 1-RF95-1/120ZE eli-m-a9cc65b775638f3124bb2524 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| quantity_specification | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Ferritic steel (10.8 ppm/K; 6.0 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Aluminium (23 ppm/K; 12.8 ppm/°F); Integrated solder tabs; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Aluminium (23 ppm/K; 12.8 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable | Strain gauge; 3-grid rosette; Constantan (ca 2.0); Limited temperature range; Austenitic steel (16 ppm/K; 8.9 ppm/°F); Leads; Bondable |
| Gauge resistance | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 120 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω | 120 Ω | 120 Ω | 350 Ω | 120 Ω |
| interface_specification | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown | Unknown |
| Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
