4144
From the HBK measurement microphone cartridges series
HBK measurement microphone cartridges: sensors and measurement devices by HBK for microphones.
- Frequency response
- 2.6–8000 Hz
- Number of measurement channels
- 1
- Maximum SPL
- 146 dB SPL
Technical specification
Every engineering figure, laid out to scan quickly
| Microphone diameter | 1 inch |
|---|---|
| Microphone polarization | v_d6bc5a7f9225d591 |
| A-weighted inherent noise | 11 dB(A) |
| Maximum SPL | 146 dB SPL |
| Frequency response | 2.6–8000 Hz |
| Interfaces | ethernet |
| Number of measurement channels | 1 |
| quantity_specification | 2.6-8,000 Hz; 11-146 dB SPL. |
| ADC sampling rate | 131072 samples/s |
| Sound field | v_f6023b0503dfda71 |
| source_sampling_rate_basis | The stated microphone bandwidth is retained. The cited compatible DAQ tier is selected so that its sample rate exceeds the microphone upper-band requirement. |
| source_acoustic_standard | IEC 61094 measurement microphone |
